Annotations Libraries Presets
LOGIQ 7 Basic User Manual 16-49
Direction 2392206-100 Rev. 1
Annotations Libraries Presets
Overview
Annotation screens allow you to specify annotation text and
pointer options, to define annotation libraries, and assign
annotation libraries to applications.
Annotations Libraries/Libraries Preset Menu
On the Annotations Libraries tab, you can change and create
annotation libraries. An annotation library is a list of annotations
that are associated with a specific application. The annotations
are listed in the library in the order in which they display on the
Touch Panel. For each library, you can define two Touch Panel
displays of annotations (Page1 and Page2), with 15 annotations
on each Touch Panel.
Figure 16-39. Annotation Libraries Preset Menu
