Optimizing the Image
5-60 LOGIQ 7 Online Help
Direction 2392536-100 Rev. 1
LOGIQView
Description LOGIQView provides the ability to construct and view a static 2D
image which is wider than the field of view of a given transducer.
This feature allows viewing and measurements of anatomy that
is larger than what would fit in a single image. Examples include
scanning of vascular structures and connective tissues in the
arms and legs.
LOGIQView constructs the extended image from individual
image frames as the operator slides the transducer along the
surface of the skin in the direction of the scan plane. The quality
of the resulting image is somewhat user-dependent and requires
some additional skill and practice to develop proper technique
and become fully proficient.
LOGIQView is not available for the following:
• Multi Image
• Timeline Modes
• B Flow Mode
• Color Flow Mode
• PDI Mode
Benefits The user can look at a larger region of interest within one field of
view that is wider than any given probe would normally provide.
Clinical Use LOGIQView is intended for scanning areas too large to fit on one
image.
Using LOGIQView To perform an exam using LOGIQView,
1. Perform a detailed examination of the anatomy/pathology.
Optimize parameters for tissue texture and visible window
PRIOR TO activating LOGIQView.
2. Press the LOGIQView key on the Control Panel.
3. To start acquiring the image, press ‘L’ (the left split screen
key).
HINTS
When you scan, scan slowly and in a uniform motion
lengthwise, end-to-end (with or against the probe orientation
marker). LOGIQView acquires images via leading edge vectors
(and does not acquire slices, as in CINE). The image is being
stored as you perform the scan and you can watch the
LOGIQView as it is being acquired.
To Next Page
