Customizing Your System
16-94 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Dataflow
A dataflow is a set of pre-configured services. When you select
a dataflow, the ultrasound system automatically works according
to the services associated with the dataflow. The Dataflow tab
allows you to select and review information about dataflows. You
can also create, change, and remove dataflows.
Set up dataflows for the services. Workflow MUST be PRIMARY
in a dataflow. Also, Query/Retrieve MUST be the only service in
a dataflow -- also, set it to Hidden so that it cannot be selected
from the Patient menu.
NOTE: You must be logged on as Administrator to use the Dataflow tab.
Figure 16-66. Dataflow Preset Menu
Table 16-56: Dataflow
Preset Parameter Description
Name Select the dataflow from the list.
Direct Store Select to store data directly to archive (no buffer
storage).
Hidden Select so that this dataflow does not appear as a
Dataflow on the Patient menu.
Default Dataflow Select to use this dataflow as the default dataflow
when you start the system.
Role Select the priority of the service:Primary - first
priority (can be assigned to input, output, or I+O
services). Secondary - second priority (can be
assigned to input, output, or I+O services). Primary
output - allows primary assignment to an output
service even if an I+O service is already defined as
primary. You can have a primary out with an I/O and
a Primary with Input Service only. You cannot have
a primary In and Primary. If you assign a primary
role to two services with the same direction, the
system displays a warning. It prompts you to re-
define one of the services as secondary.
