Optimizing M-Mode
LOGIQ 7 Online Help 5-65
Direction 2392536-100 Rev. 1
Scanning Hints
Sweep Speed
Description Changes the speed at which the timeline is swept.
Available in M-Mode and Doppler Mode.
Available in M Color Flow Mode.
Adjusting To increase/decrease, select Sweep Speed.
Values Each selection represents a different sweep time; values vary by
probe and application.
Sweep Speed values are returned to the factory or user preset
value when you change the following: Probe, Exam Category,
Exam Calcs, or New Patient.
Benefits You can speed up or slow down the timeline to see more or
fewer occurrences over time.
Bioeffects Changing the Sweep Speed may change the TI and/or MI.
Observe the output display for possible effects.
HINTS
These M-Mode controls produce the following results:
Edge Enhance. Affects border sharpness.
Sweep Speed. Controls speed of M-Mode update.
Dynamic Range. Affects the amount of gray scale information
displayed.
