Preparing the System for Use
3-38 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Connecting the Probe
Probes can be connected at any time, regardless of whether the
console is powered on or off. To ensure that the ports are not
active, place the system in the image freeze condition.
To connect a probe:
1. Place the probe's carrying case on a stable surface and
open the case.
2. Carefully remove the probe and unwrap the probe cord.
3. DO NOT allow the probe head to hang free. Impact to the
probe head could result in irreparable damage. Use the
integrated cable management hook to wrap the cord.
4. Turn the connector locking handle counterclockwise.
5. Align the connector with the probe port and carefully push
into place.
6. Turn the connector locking handle clockwise to secure the
probe connector.
7. Carefully position the probe cord so it is free to move and is
not resting on the floor.
CAUTION
Fault conditions can result in electric shock hazard. Do not
touch the surface of probe connectors which are exposed
when the probe is removed. Do not touch the patient when
connecting or disconnecting a probe.
