GE LOGIQ 7 Basic User Manual

Console Overview
LOGIQ 7 Basic User Manual 3-5
Direction 2392206-100 Rev. 1
Console Overview
Console graphics
The following are illustrations of the console:
Figure 3-1. LOGIQ 7 System (right and left side views)
1. Probe and Gel Bottle Holder
2. Storage area of Peripheral Device
3. Storage area of Peripheral Device (located beneath the
control panel)
25
3
4
1
6
3
CAUTION
DO NOT place probes or the footswitch into either the side
pocket or the peripheral device’s storage area.
