Preparing the System for Use
3-6 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Console graphics (continued)
Figure 3-2. LOGIQ 7 System (front and back views)
1. Optional B/W Video Page Printer
2. Footswitch connector
3. External Disk Drive and Optional Physiological Input Panel
- DVD Multi Drive and ECG
- DVD Multi Drive, ECG and MOD
- MOD and DVD Multi Drive
4. Probe Connector
5. Front Pedal
6. Hinged Peripheral cable Access Panel Door
7. Rear Pedal
8. Task Lamp
1
2
8
4
3
5
6
7
To Next Page
