Standard Report Pages
LOGIQ 7 Basic User Manual 14-5
Direction 2392206-100 Rev. 1
Activating the Report
1. Select Report on the Touch Panel.
2. The system displays the default report for the current
application on the monitor and Report Touch Panel.
3. Adjust the Page Change control to move the lower half of
the report.
Selecting another template
To change the report from the default to another template:
1. Position the cursor to TEMPLATE at the bottom of the
monitor display.
2. An Application list displays.
Figure 14-3. Application List Example
3. Select the desired application and press Set.
4. An available template list displays.
Figure 14-4. Available Template list
5. Select the desired template name and press Set.
6. The report changes to the selected template.
