OB/GYN
9-98 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Doppler Mode Measurements
Doppler measurements for the Gynecology exam are identical
to Doppler measurements for the Obstetrics exam. These
measurements include the following vessels: uterine, ovarian,
umbilical, middle cerebral artery, aorta, placenta, and
descending aorta. For each vessel, you can make any of the
following measurements: peak systole, minimum diastole, end
diastole, heart rate, TAMAX, pulsatility index, resistive index,
acceleration, PS/ED, ED/PS, and acceleration time.
For details regarding these measurements, See ‘Doppler Mode
Measurements’ for more information.
Figure 9-35. Doppler Mode General Gynecology study
