Preparing the System for Use
3-10 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Peripheral/Accessory Connection
Peripheral/Accessory Connector Panel
LOGIQ 7 peripherals and accessories can be properly
connected using the rear connector panel located behind the
rear door. Only the B/W Printer can be connected to the front
accessory panel.
Located on the rear panel are video input and output, audio
input and output, camera rec/expose, Insite, Ethernet, power
and control connections for VCR, printer and service tools. See
Figure 3-6 for more specifics.
CAUTION
Each outer (case) ground line of peripheral/accessory
connectors are Earth Grounded.
Signal ground lines are Not Isolated.
CAUTION
Use only approved probes, peripherals or accessories.
Be sure to plug the power supply cable of the peripherals to the
connector panel of the system to avoid unexpected electrical
shock.
DO NOT connect any probes or accessories without approval
by GE.
