Customizing Your System
16-76 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Device
To add a new device,
1. Press Add.
2. Type the device name in the Name field.
3. Type the device’s IP address in the IP Address field.
Figure 16-53. Connectivity Device Preset Menu
To ping a device,
1. Select the device.
2. Press Ping. If the smiley face smiles, then the connection
has been confirmed. If the smiley face frowns, then the
connection has not been made. Check the device name and
IP address.
Table 16-43: Device
Preset Parameter Description
Add/Remove Press Add to add a new device; press Remove to
delete a device.
Ping Press Ping to confirm that a device is connected.
Properties: Name Type the name of the device.
Properties: IP
Address
Type the device’s IP address.
To Next Page
