Adjusting the Display Monitor
LOGIQ 7 Basic User Manual 3-31
Direction 2392206-100 Rev. 1
Adjusting the Display Monitor
Rotate, tilt, raise and lower the monitor
The monitor position can be adjusted for easy viewing.
• The monitor can be rotated around its central pivot point.
• The monitor can be tilted for the optimum viewing angle.
• The monitor and console panel can be raised or lowered for
the best viewing height.
NOTE: When moving the LOGIQ 7, lower and lock the monitor and
console panel to its lowest possible position to improve stability.
CAUTION
Be careful when lowering the monitor and control panel that it
does not collide with the peripheral device sitting on the top of
the console. Use caution and slowly lower the monitor and
control panel.
DO NOT place objects on the monitor.
