GE LOGIQ 7 Basic User Manual

Preparing the System for Use
3-30 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Setting the front wheels lock (continued)
The pedal which is located between the rear wheels of the unit
enables the user to control the movement of the wheels.
Figure 3-17. Rear Pedal
Table 3-5: Rear Pedal Functions
Pedal Position Function
1.
Left Swivel lock
2.
Right Free
21
CAUTION
When two or more people are releasing the swivel/pivot wheel
controls with the front and rear pedals, take extra precaution to
prevent unexpected movement which could result in possible
toe injuries.
