Powering the System
LOGIQ 7 Basic User Manual 3-15
Direction 2392206-100 Rev. 1
Powering the System
Connecting and Using the System
To connect the system to the electrical supply:
1. Ensure that the wall outlet is of the appropriate type.
2. Ensure that the power switch is turned off.
3. Unwrap the power cable. Make sure to allow sufficient slack
in the cable so that the plug is not pulled out of the wall if the
system is moved slightly.
4. Attach the power plug to the system and secure it in place
by using the retaining clamp.
Figure 3-9. Power Plug
a. Retaining clamp for power plug
5. Push the power plug securely into the wall outlet.
a
CAUTION
Ensure that the retaining clamp for the power plug is fixed
firmly.
CAUTION
Use caution to ensure that the power cable does not
disconnect during system use.
If the system is accidentally unplugged, data may be lost.
To Next Page
