Console Overview
LOGIQ 7 Basic User Manual 3-9
Direction 2392206-100 Rev. 1
Task Lamp
The task lamp is used to illuminate the keyboard.
Figure 3-4. Task lamp
1. Task lamp
2. Light Volume Control knob
Adjust the knob clockwise to increase the light’s brightness.
Adjust the knob counterclockwise to dim the light.
Figure 3-5. Task Lamp Light Control knob
CAUTION
The task lamp may overheat. Take proper precautions to avoid
touching the task lamp.
Contact your local Service Representative when the task lamp
bulb needs to be replaced.
1
2
