GE LOGIQ 7

Preparing the System for Use
3-8 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Storage areas
Several convenient storage areas are provided within the
console as shown in the figure below. Use them to store gel,
options, probe cables, accessories, etc.
Figure 3-3. Storage Areas
1. Storage Areas
1
1
1
1
1
1
1
1
1
CAUTION
DO NOT place probes or the footswitch into either the side
pocket or the peripheral device’s storage area.
