Optimizing B-Mode
LOGIQ 7 Online Help 5-21
Direction 2392536-100 Rev. 1
N S-shaped map. This map highlights tissue differentiation for a certain band of signals. Useful
when imaging structures where you want more contrast, e.g., renal, tendon, vein, carotid,
thyroid, breast, Cardiology, etc.
O S-shaped map. This map highlights tissue differentiation for a certain band of signals. Useful
when imaging structures where you want more contrast, e.g., renal, tendon, vein, carotid,
thyroid, breast, Cardiology, etc.
P Assigns a lesser amount of gray scale pixel values to weak reflectors in the image than Map M.
Useful when imaging abdomen and liver.
Q Assigns a lesser amount of gray scale pixel values to weak reflectors in the image than Map R.
Useful when imaging thyroid and abdomen.
R Assigns a lesser amount of gray scale pixel values to weak reflectors in the image than Map C.
Useful when imaging thyroid and abdomen.
S For Contrast Mode
T For Contrast Mode
U For Contrast Mode
V S-shaped map. This map highlights tissue differentiation for a certain band of signals. Useful
when imaging structures where you want more contrast, e.g., cardiology.
W S-shaped map. This map highlights tissue differentiation for a certain band of signals. Useful
when imaging structures where you want more contrast, e.g., cardiology.
X S-shaped map. This map highlights tissue differentiation for a certain band of signals. Useful
when imaging structures where you want more contrast, e.g., cardiology.
Map Description
