Optimizing the Image
5-118 LOGIQ 7 Online Help
Direction 2392536-100 Rev. 1
3D Acquisition Parameter Description
Figure 5-57. 3D Acquisition
Table 5-8: 3D Acquisition Description and Instructions for Use
3D Parameter Description
Application
Presets
Selections: None, OB - Baby Face, Vascular
None. No application preset applied.
OB - Baby Face. After having scanned in this mode, certain rendering parameters
are set automatically. The gray surface mode is activated and the texture mode is
switched off. The gray surface mode values for opacity and threshold are set
automatically according to the datasets histogram.
Vascular. Available only with Advanced 3D or Tru 3D package. After having scanned
in this mode, certain rendering parameters are set automatically. The color image is
rendered in the texture mode. The values for opacity and threshold of the texture
mode are set automatically according to the datasets histogram. The B-Mode image
is rendered in the gray surface mode. Opacity and threshold values are defined
according to the histogram.
