Introduction
LOGIQ 7 Basic User Manual 7-7
Direction 2392206-100 Rev. 1
List of general measurements
The following table shows the types of general measurements
available when you press Measure but do not choose a specific
calculation. The type of measurement depends on the current
scan mode and the number of times Measure is pressed.
NOTE: The type of measurement repeats as you press Measure. For
example, in M–Mode, when you press Measure the fourth time,
the Tissue depth measurement is available, and so on.
Table 7-1: General Measurements by Mode
If you press
Measure
(while frozen)
MODE
B and CF Doppler M
Once • Distance
• Circumference and area
(ellipse)
Velocity Tissue depth
Twice Circumference and area
(trace)
TAMAX, TAMIN, and
TAMEAN
Time interval
Three times Two velocities,
slope, and time interval
Depth difference, slope,
and time interval
Four times Time interval
