Safety
2-12 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
“ON” indicates the power on position
of the power switch.
CAUTION: This Power Switch DOES
NOT ISOLATE Mains Supply.
“Standby” indicates the power standby
position of the power switch.
CAUTION: This Power Switch DOES
NOT ISOLATE Mains Supply.
See Figure 3-14 for location
information.
“Protective Earth” indicates the
protective earth (grounding) terminal.
Internal
“Equipotentiality” indicates the
terminal to be used for connecting
equipotential conductors when
interconnecting (grounding) with other
equipment.
Rear of console
Table 2-2: Label Icons
Label/Icon Purpose/Meaning Location
