OB/GYN
9-22 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Antero-PosteroTrunk Diameter by Transverse Trunk Diameter (AxT)
Make two distance measurements, one of the antero-postero
trunk diameter and one of the transverse trunk diameter.
1. Select AxT; an active caliper displays.
2. Make a distance measurement of the antero-postero trunk
diameter:
a. To position the active caliper at the start point, move the
Trackball.
b. To fix the start point, press Set.
The system fixes the first caliper and displays a second
active caliper.
c. To position the second active caliper at the end point,
move the Trackball.
A dotted line connects the measurement points.
d. To complete the measurement, press Set.
The system displays the distance value in the Results
Window and displays an active caliper.
3. To make a distance measurement of the transverse trunk
diameter, repeat steps a–d above.
The system displays the antero-postero trunk diameter, the
transverse trunk diameter, and AxT in the Results Window.
USA
Europe
Tokyo
Osaka
ASUM
