Declaration of Immunity
This system is suitable for use in the following environment. The
user must assure that the system is used according to the
specified guidance and only in the electromagnetic environment
listed.
Table 2-7: Declaration of Immunity
Immunity Type Test Level Compliance EMC Environment and Guidance
IEC 61000-4-2
Static discharge
(ESD)
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, concrete, or
ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30%.
Mains power quality should be that of a
typical commercial and/or hospital
environment. If the user requires
continued operation during power mains
interruptions, it is recommended that the
system be powered from a UPS or a
battery.
NOTE: UT is the a.c. mains voltage prior
to application of the test level.
Power frequency magnetic fields should
be at levels characteristic of a typical
location in a typical commercial and/or
hospital environment.
Separation distance to radio
communication equipment must be
maintained according to the method
below. Interference may occur in the
vicinity of equipment marked with the
symbol:
IEC 61000-4-4
Electrical fast
transient/burst
± 2 kV for mains
± 1 kV for SIP/
SOP
± 2 kV for mains
± 1 kV for SIP/
SOP
IEC 61000-4-5
Surge Immunity
± 1 kV differential
± 2 kV common
± 1 kV differential
± 2 kV common
IEC 61000-4-11
Voltage dips,
short interruptions
and voltage
variations on
mains supply
< 50
T
(> 95% dip)
for 0.5 cycle;
400
T
(60 0ip) for 5
cycles;
700
T
(30 0ip) for
25 cycles;
< 50
T
(>95% dip)
for 5 sec
< 50
T
(> 95% dip)
for 0.5 cycle;
400
T
(60 0ip) for 5
cycles;
700
T
(30 0ip) for
25 cycles;
< 50
T
(>95% dip)
for 5 sec
IEC 61000-4-8
Power frequency
(50/60 Hz)
magnetic field
3 A/m 3 A/m
IEC 61000-4-6
Conducted RF
3 V
RMS
150 kHz - 80 MHz
3 V
RMS
150 kHz - 80 MHz
IEC 61000-4-3
Radiated RF
3 V/m
80 MHz - 2.5 GHz
3 V/m
80 MHz - 2.5 GHz
NOTE: These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects, and people.
