Cardiology
10-114 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Table 10-4: Template Settings
Parameter Description
Template Settings • Cycles: select the number of cine loop heart cycles to store for each level
from the pull-down menu or enter the desired value manually.
• Continuous Capture: Checking this parameter enables continuous image
acquisition throughout the level. The images acquired are temporarily
stored in the system’s storage buffer.
• Preview of store: Checking this parameter enables review and
adjustment of cine loops before store.
• Show reference: Checking this parameter displays a dual screen with the
reference level (first or previous level) on the left and the live image on
the right.
Table 10-5: Other options
Parameter Description
Other Options • Grid Size ; Enter the number of levels and projections for the selected
template.
• Timers: If you check this parameter, starts T1 and T2 timers
automatically.
• Auto-start analysis: If you check this parameter, displays the Stress Echo
Analysis when the last acquisition is performed.
• Reference image: When Show Reference is selected, selects either
corresponding baseline loop or corresponding loop from the previous
level to be displayed as reference image during acquisition.
Table 10-6: Pre-defined groups
Parameter Description
Pre-defined groups • Shows the image groups created.
• New group: Creates a new image group. Select the desired images on
the template preview.
• Update group: Edits a selected group after new loop selection on the
template preview.
• Delete group: Deletes a selected group.
