Image/Data Management
LOGIQ 7 Basic User Manual 15-13
Direction 2392206-100 Rev. 1
Save As (Saving Images to the media to View on Any PC) (continued)
6. Specify Compression and Save As Type and press Save.
The image is saved to the media.
7. When you have put all the images you want on the media,
press F3 to eject the media. Select CD/DVD Rewritable or
3½ MO disk.
8. Finalize the media by selecting Yes. The media is ejected
from the system.
Figure 15-3. Finalize CD-ROM Menu
NOTE: If you want to add more images to the media, select “No”.
Storing Images with More Resolution
To store images with more resolution than is available with the
JPEG selection, select Save As and select AVI as the Save As
Type. You can save single images as .avi files.
Table 15-1: Store Options
Image Type
Store as Image
Only
Store as
Secondary Capture
CINE Loop Gives you a loop of just
the image (no title bar
and scan information).
Gives you a single
image of the video
area. DO NOT DO
THIS BECAUSE YOU
DO NOT KNOW
WHICH IMAGE FROM
THE LOOP THAT YOU
ARE GETTING.
Still Image Gives you a single
image (no title bar and
scan information).
Gives you a single
image of the video
area.
