GE LOGIQ 7 Basic User Manual

Customizing Your System
16-18 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
System/System Imaging Preset Menu (continued)
Table 16-8: Biopsy Guides
Preset Parameter Description
Show Center Line Displays center biopsy guideline.
Show Outer Lines Displays outer biopsy guidelines.
Enable 0.5cm
markers
Activates biopsy depth markers every 0.5cm.
Table 16-9: Image Control and Display
Preset Parameter Description
Horizontal Scale Select to display width markers.
TGC Display Select to display TGC curve.
PW Velocity Units in
cm/s
Select to change scale on timeline from centimeters
per second to meters per second.
Split screen full
height display of
linear images
When selected, while in split screen and using a
linear probe, the system clips the sides of images
so that the image can fill the available display.
Use full height in
Zoom on linear
images
Select to use full height zoom while scanning on a
linear image.
Increase display
image size
Increases the size of the displayed image. After you
save this feature, go back to scanning, press B-
Mode or reboot the system. The image size
changes.
Auto Invert on Linear
Steer
When selected, for auto calcs, automatically inverts
the timeline if needed when using ASO.
Auto Invert on ASO Automatically inverts the spectrum with ASO.
Audio Volume Adjusts the Doppler audio volume via a drop-down
menu (for example, 0=softer; 31=louder).
Auto Freeze (15
minutes)
Automatically freezes the system after 15 minutes
of inactivity.
Image Parameter
Size (reboot required)
Choose Small, Medium, or Large. Must reboot the
system.
