System Presets
LOGIQ 7 Basic User Manual 16-33
Direction 2392206-100 Rev. 1
Restore procedure: patient data
1. Insert the Backup/Restore CD into the CD-RW drive.
2. On the Touch Panel, press Utility.
3. On the Utility Touch Panel, press System.
4. On the monitor display, select Backup/Restore.
The Backup/Restore screen is displayed.
NOTE: If you are not logged in with administrator privileges, the
Operator Login window is displayed. Log on with
administrator privileges.
5. In the Restore list, select Patient Archive.
6. In the Media field, select the Backup/Restore CD.
7. Select Restore.
The system performs the restore. As it proceeds, status
information is displayed on the Backup/Restore screen.
CAUTION
The restore procedure overwrites the existing database on the
local hard drive. Make sure to insert the correct CD.
