Customizing Your System
16-78 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Adding a service to a destination device
1. Select the service from the pull-down menu. Press Add.
2. Specify the properties for this service. Press Save.
3. Verify the service.
Removing a service
1. Select the service. Press Remove.
2. Press Save.
Changing parameters for a service
There are certain parameters that may need to be set up for
each service:
Table 16-44: Service Parameters: Common Service Parameters
Preset Parameter Description
Name Free text: give a descriptive name to the device.
AE Title The Application Entity Title for the service.
Port Number The port number of the service.
Maximum Retries Max # – the maximum number of times to try
establishing a connection to the service..
Retry Interval (sec) Specify how often (in seconds) the system should
try to establish a connection to the service.
Timeout The amount of time after which the system will stop
trying to establish a connection to the service.
