Customizing Your System
16-80 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
DICOM Image Storage
DICOM Image Storage allows the system to send or receive
ultrasound images in a format that can be interpreted by PACS.
Figure 16-55. DICOM Image Storage Service
Table 16-45: DICOM Image Storage
Preset Parameter Description
Allow Multiframe Select to allow cine loop storage.
Allow raw data Select to save data in both TruAccess (raw data)
and DICOM format.Clear to save in DICOM format
only.
Compression Select the compression type: None, Rle, or Jpeg.
Quality % Set picture quality from 1 to 100%. A low picture
quality level allows high data compression, while a
high picture quality restrains the compression.
Max Framerate Select the maximum frame rate: Full, 25, or 30.
Color Support Select: Mixed, Gray or Color
Reopen per image Reopen per image
Enable Structured
Reporting
Select for Structured Reporting.
