GE LOGIQ 7

Preparing the System for Use
3-34 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Brightness and Contrast (continued)
To adjust the contrast:
1. Press the Toggle button on the display monitor once.
2. Press the Adjustment (+) button to increase contrast. Press
the Adjustment (-) button to decrease contrast.
The amount of contrast is shown on a slide bar on the
screen.
Figure 3-19. Brightness and Contrast
To adjust the brightness:
1. Press the Toggle button on the display monitor twice.
2. Press the Adjustment (+) button to increase brightness.
Press the Adjustment (-) button to decrease brightness.
The amount of brightness is shown on a slide bar on the
screen.
1
2
345
1. Contrast Indicator 4. Brightness/Contrast Adjustment (-)
Button
2. Brightness Indicator 5. Brightness/Contrast Adjustment (+)
Button
3. Brightness/Contrast Toggle Button
