LOGIQ 7 Features/Specifications (continued)
Table 18-3: System Parameters
Post-Processing
• B/M-Mode (Grey Map; Rejection; Colorized B and
M; Frame Averaging)
• D-Mode (Grey Map; Rejection; Colorized D)
• Color Flow (Color Map; CFM Display Threshold)
Pre-Processing
• B/M-Mode (Gain; TGC; Dynamic Range;
Transmission Focus Position; Transmission Focus
Number; Transmission Frequency; Edge
Enhancement; Frame Rate Control; Image
Softener Level; Sweep Speed for M-Mode)
• D-Mode (Gain; Dynamic Range; Transmission
Frequency; Velocity Scale/PRF; Wall Filter;
Baseline Shift; Sweep Speed)
• Color Flow (CFM Gain; CFM Velocity Range; MTI
Filter; Pulse Packet Size; Frame Rate Control;
CFM Spatial Filter; CFM Frame Averaging;
Diagnostic Color Display Mode; Baseline Shift;
CFM ACE-Filter)
Image Processing and Presentation
• Image Reverse: Right/ Left
• Image Rotation: 4 steps, Rotation: 0°, 90°, 180°,
270°
• Imaging Depth: 0-30cm [Minimum: 0-1 cm (Zoom);
Maximum: 0-30 cm]
• Transmission Focus [1-8 Focus Points selectable;
Focus Position: 8 steps
• Receiving Focus [CDA/CDF (Continuous Dynamic
Focus/Continuous Dynamic Aperture)]
• 256 Shades of Grey
Zoom
• Smart Zoom (Acoustic Write Zoom):
• Reference Image for Smart Zoom
• Read Zoom (available in B/ M and CFM)
Physiological Input Panel (Option)
• Physiological Input (ECG, 1 channel; PCG, 1
channel; AUX, 2 channel)
• Dual R-Trigger
• Reference Scan: Simultaneous Display of Active
Image and Trigger Update Image
• Presetable ECG R Delay Time
• Presetable ECG Position
• Adjustable ECG Gain Control
• Presetable PCG Position
• Adjustable PCG Gain Control
• Presetable AUX Gain Control
• Adjustable AUX Gain Control
• Automatic Heart Rate Display
Image Archive
• Archiving Format: DICOM
• Possibly exported to other format
CINE Memory/Image Memory
• Dual Image CINE Display
• CINE Gauge and CINE Image number display
• CINE Review Loop
• Selectable CINE Sequence for CINE Review (by
Start Frame and End Frame)
• Side Change in dual CINE Mode
• Measurements/Calculations & Annotations on
CINE & VCR Playback Images
