Tables and Overviews | Technical Information
20
796
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
User functions
■
SubprogramsProgram jumps
■
Program section repeats
■
Any desired program as subprogram
■
Cycles for drilling, and conventional and rigid tapping
■
Roughing of rectangular and circular pockets
x Cycles for pecking, reaming, boring, and counterboring
x Cycles for milling internal and external threads
x Finishing of rectangular and circular pockets
x Cycles for clearing level and inclined surfaces
x Cycles for milling linear and circular slots
x Cartesian and polar point patterns
x Contour-parallel contour pocket
Machining cycles
x Contour train
x OEM cycles (special cycles developed by the machine manufacturer)
can also be integrated
■
Datum shift, rotation, mirroringCoordinate transformation
■
Scaling factor (axis-specific)
1 Tilting the working plane (Advanced Function Set 1)
■
Mathematical functions =, +, –, *, /, roots
■ Logical operations (=, ≠, <, >)
■
Calculating with parentheses
■ sin α, cos α, tan α , arc sin, arc cos, arc tan, a
n
, e
n
, In, log, absolute
value of a number, constant π, negation, truncation of digits before or
after the decimal point
Q parameters
Programming with variables
■
Functions for calculation of circles
■
String param.
■
Calculator
■
Complete list of all current error messages
■
Context-sensitive help function for error messages
■
TNCguide: The integrated help system.
Programming aids
■
Graphic support for the programming of cycles
■
Comment and structure blocks in the NC program
Teach-In
■
Actual positions can be transferred directly to the NC program
x Graphical simulation before a program run, also while another program
is being run
Test graphics
Display modes
x Plan view / projection in 3 planes / 3-D view / 3-D line graphics
x Detail enlargement
