HEIDENHAIN TNC 620 Programming Station User Manual

Tables and Overviews | Technical Information
20
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
797
User functions
Programming graphics
■
In Programming mode, the contour of the NC blocks is drawn on
screen while they are being entered (2-D pencil-trace graphics), even if
another program is running
Program-run graphics
Display modes
x Graphic simulation of real-time machining in plan view / projection in 3
planes / 3-D view
Machining time
■
Calculation of machining time in the Test Run operating mode
■
Display of the current machining time in the Program Run, Single Block
and Program Run, Full Sequence operating modes
Datum management
■
For saving any datums
Contour, returning to
■
Block scan in any block in the program, returning the tool to the calculat-
ed nominal position to continue machining
■
Program interruption, contour departure and return
Datum tables
■
Multiple datum tables for storing workpiece-specific datums
x Calibrating the touch probe
x Compensation of workpiece misalignment, manual or automatic
x Presetting, manual or automatic
Touch probe cycles
x Automatic workpiece measurement
x Tools can be measured automatically
