Hitachi WJ C1 Series User Manual

Chapter 9 Inverter Functions
9-1-2
9.1.2 Operation by RUN Key on the Keypad
 How to operate the inverter via the keypad during a test run?
 How to operate the inverter via the RUN key on the keypad?
 To start or stop the inverter using the RUN and STOP/RESET keys on the keypad or the optional
remote operator (OPE-SR/OPE-SR mini, etc.), set the "RUN command input source selection
[A002]
*1
" parameter to "Keypad (RUN-key) (02)".
 To start operation using the RUN key on the keypad, set the correct direction of operation with
"RUN-key command rotation direction [F004]".
Code
Item
Description
Data
[A002]
*1
RUN command input
source selection
Operation is started and stopped using the RUN
and STOP/RESET keys on the keypad or optional
remote operator.
02
[F004]
RUN-key command
rotation direction
Forward rotation operation from the keypad.
00
Reverse rotation operation from the keypad.
01
[C021]
[C022]
[C026]
Output terminal
function
RUN command by keypad [REF]:
This output terminal turns on when inverter
RUN command can be initiated using the RUN
key on the keypad.
59
*1. "2nd-motor control [SET]" target parameter. The second control parameter is also subject to setting.
 For the inverter to start operation, a frequency command is required in addition to a RUN
command.
A
!
Q
