Hitachi WJ C1 Series User Manual

Chapter 18 List of Parameters/Modbus Coil/Register Numbers
18-2-2
18.2.8 H Parameter Group
Code
Name
Data range
Initial
value
Set
value
Change
during
running
Modbus communication
Page
Register No.
Data Range
Resolution
H001
Auto-tuning
selection
00: Disable
01: Enable without rotation
02: Enable with rotation
00
×
1501h
0 to 2
-
8-3-1
H002
Async. Motor
constant
selection, 1st-
motor
00: Hitachi Standard
02: Auto-tuning Data
00
×
1502h
0 to 2
-
8-1-14
8-3-1
H202
Async. Motor
constant
selection, 2nd-
motor
×
2502h
-
H003
Async. Motor
capacity, 1st-
motor
0.1/ 0.2/ 0.4/ 0.55/ 0.75/
1.1/ 1.5/ 2.2/ 3.0/ 3.7/ 4.0/
5.5/ 7.5/ 11.0/ 15.0/ 18.5
(kW)
Maximum
applicable
motor
capacity
×
1503h
0 (0.1kW)
1 (0.2kW)
2 (0.4kW)
3 (0.55kW)
4 (0.75kW)
5 (1.1kW)
6 (1.5kW)
7 (2.2kW)
8 (3.0kW)
9 (3.7kW)
10 (4.0kW)
11 (5.5kW)
12 (7.5kW)
13 (11kW)
14 (15kW)
15 (18.5kW)
-
8-1-5
H203
Async. Motor
capacity, 2nd-
motor
×
2503h
-
H004
Async. Motor
number of poles,
1st-motor
2/ 4/ 6/ to / 46/ 48 (poles)
4
×
1504h
0 (2 poles)
1 (4 poles)
2 (6 poles)
to
22 (46 poles)
23 (48 poles)
-
H204
Async. Motor
number of poles,
2nd-motor
×
2504h
-
H005
Async. Motor
speed response,
1st-motor
1 to 1000 (%)
100
✓
1506h
1 to 1000
1
9-5-12
H205
Async. Motor
speed response,
2nd-motor
✓
2506h
1
H006
Async. Motor
stabilization
constant, 1st-
motor
0 to 255
100
✓
1507h
0 to 255
1
9-5-10
H206
Async. Motor
stabilization
constant, 2nd-
motor
✓
2507h
1
H020
Async. Motor
constant R1, 1st-
motor
0.001 to 65.535 (Ω)
Depending
on
capacity
×
1516h
1 to 65535
0.001
8-1-14
9-5-12
H220
Async. Motor
constant R1,
2nd-motor
×
2516h
0.001
H021
Async. Motor
constant R2, 1st-
motor
0.001 to 65.535 (Ω)
Depending
on
capacity
×
1518h
1 to 65535
0.001
H221
Async. Motor
constant R2,
2nd-motor
×
2518h
0.001
H022
Async. Motor
constant L, 1st-
motor
0.01 to 655.35 (mH)
Depending
on
capacity
×
151Ah
1 to 65535
0.01
H222
Async. Motor
constant L, 2nd-
motor
×
251Ah
0.01
