Hitachi WJ C1 Series User Manual

Chapter 7 Keypad and Related Functions
7-2-1
7.2 Functions Related to Keypad
7.2.1 Restrict Display Parameter
 How can display only the necessary parameters?
 How can display fewer parameters?
 How can display only the changed parameters?
 Parameters displayed in the keypad can be partially hidden by setting "Display restriction
selection [b037]".
 To show all parameters, set [b037] to "Full display (00)".
 To display parameters that have been changed from the values at initialization, set [b037] to
"Data comparison display (03)".
 [b037] setting can be password protected. For details, see "7.2.4 Protecting Data with
Passwords".
Code
Item
Description
Data
[b037]
Display
restriction
selection
Full display (initial value)
00
Function-specific display
01
User settings (Parameters set in [U001] to [U032] and
[d001], [F001], [b037], [b190] and [b191] are
displayed.)
02
Data comparison display
03
Monitor only ([d ***], [b037], [b190] and [b191])
05
[U001]
to
[U032]
User-parameter 1
selection to
User-parameter
32 selection
No registration
no
Register the parameter code to be displayed.
Up to 32 parameters can be registered.
[d001]
to
[P196]
■ Details of each setting of "Display restriction selection [b037]"
"Display restriction selection
[b037]" setting
Details
Full display (00)
Displays all parameters.
Function-specific display (01)
Use this when you want to hide the parameters of unused functions
and display fewer parameters. If a specific function is not selected, the
parameters associated with that function are hidden.
Refer to the table on the next page for details of display conditions.
User Settings (02)
Use to display only arbitrary parameters set by the user.
Up to 32 arbitrary parameters can be registered in "User-parameter 1
to 32" ([U001] to [U032]).
When "Display restriction selection [b037]" is set to "User settings (02)"
after registration, only parameters registered in [U001] to [U032] and
[d001], [F001], [b037], [b190] and [b191] are displayed.
Data comparison display (03)
Used to know the parameter changed from the factory setting.
All monitor displays [d ***] and [F001], [b037], [b190] and [b191] are
also displayed.
Monitor only (05)
Only all monitor displays [d ***], [b037], [b190], and [b191] are
displayed.
A
Q
