Chapter 18 List of Parameters/Modbus Coil/Register Numbers
18-1-1
18.1 List of Modbus Coil Numbers/Special Register Numbers
18.1.1 List of Modbus Coil Numbers
*1. The input terminal can be turned on/off by Modbus communication. The inverter recognizes that the input
terminal is in the ON state if either the input terminal by communication or the input signal by control terminal is
on. However, as the Intelligent Input terminal monitor [d005] is a monitor of control terminal's input signal, input
status via communication is not displayed.
Coil
number
Item name
R/W
Setting
0000h
Not used
-
Not accessible
0001h
RUN command
R/W
1: Run / 0: Stop (enabled when [A002]/ [A202] = 03)
0002h
Rotation direction command
R/W
1: Reverse / 0: Forward (enabled when [A002]/ [A202] = 03)
0003h
External trip (EXT)
R/W
1: Trip
0004h
Reset (RS)
R/W
1: Reset
0005h
(Reserved)
-
-
0006h
(Reserved)
-
-
0007h
Intelligent input terminal 1
*1
R/W
1: ON / 0: OFF
0008h
Intelligent input terminal 2
*1
R/W
1: ON / 0: OFF
0009h
Intelligent input terminal 3
*1
R/W
1: ON / 0: OFF
000Ah
Intelligent input terminal 4
*1
R/W
1: ON / 0: OFF
000Bh
Intelligent input terminal 5
*1
R/W
1: ON / 0: OFF
000Ch
Intelligent input terminal 6
*1
R/W
1: ON / 0: OFF
000Dh
Intelligent input terminal 7
*1
R/W
1: ON / 0: OFF
000Eh
(Reserved)
-
-
000Fh
Operation status
R
1: Run / 0: Stop (linked to [d003])
0010h
Rotation direction
R
1: Reverse / 0: Forward (linked to [d003])
0011h
Inverter ready
R
1: Ready / 0: Not ready
0012h
(Reserved)
-
-
0013h
RUN (Running)
R
1: ON / 0: OFF
0014h
FA1 (Constant-frequency reached)
R
1: ON / 0: OFF
0015h
FA2 (Set frequency overreached)
R
1: ON / 0: OFF
0016h
OL (Overload warning notice)
R
1: ON / 0: OFF
0017h
OD (Over deviation for PID control)
R
1: ON / 0: OFF
0018h
AL (Alarm)
R
1: ON / 0: OFF
0019h
FA3 (Set frequency reached)
R
1: ON / 0: OFF
001Ah
OTQ (Over-torque/under-torque)
R
1: ON / 0: OFF
001Bh
(Reserved)
-
-
001Ch
UV (Undervoltage)
R
1: ON / 0: OFF
001Dh
TRQ (Torque limited)
R
1: ON / 0: OFF
001Eh
RNT (Accumulated operation time over)
R
1: ON / 0: OFF
001Fh
ONT (Accumulated power-on time over)
R
1: ON / 0: OFF
0020h
THM (Electronic thermal alarm (Motor))
R
1: ON / 0: OFF
0021h
(Reserved)
-
-
0022h
(Reserved)
-
-
0023h
(Reserved)
-
-
0024h
(Reserved)
-
-
0025h
(Reserved)
-
-
0026h
BRK (Brake release)
R
1: ON / 0: OFF
0027h
BER (Brake error)
R
1: ON / 0: OFF
0028h
ZS (Zero speed detection)
R
1: ON / 0: OFF
0029h
DSE (Speed over deviation)
R
1: ON / 0: OFF
002Ah
POK (Positioning complete)
R
1: ON / 0: OFF
002Bh
FA4 (Set frequency overreached 2)
R
1: ON / 0: OFF
