Hitachi WJ C1 Series

Chapter 18 List of Parameters/Modbus Coil/Register Numbers
18-2-24
18.2.6 List of Intelligent Input Terminal Functions
Function
Number
Symbol
Function name
Page
00
FW
Forward rotation
9-1-3
01
RV
Reverse rotation
02
CF1
Multi-speed selection 1
9-2-7
03
CF2
Multi-speed selection 2
04
CF3
Multi-speed selection 3
05
CF4
Multi-speed selection 4
06
JG
Jogging
9-2-10
07
DB
External DC braking
9-7-11
08
SET
2nd-motor control
9-7-18
09
2CH
2-stage
Acceleration/Deceleration
9-3-3
11
FRS
Free run stop
9-7-9
9-7-10
12
EXT
External fault
9-10-3
13
USP
Unattended start
protection
9-10-4
14
CS
Commercial power supply
change
9-7-15
15
SFT
Soft-Lock
7-2-5
16
AT
Analog input switching
9-2-4
18
RS
Reset
9-1-9
9-7-8
19
PTC
External thermistor
Can be assigned only to [C005].
5-4-4
9-10-7
20
STA
3-wire Start
9-1-4
21
STP
3-wire Stop
22
F/R
3-wire Forward/Reverse
23
PID
Disable PID
9-8-2
24
PIDC
PID integration reset
27
FUP
Remote control Speed-UP
function
9-2-18
28
FDN
Remote control Speed-
DOWN function
29
UDC
Remote control Speed data
clearing
31
F-OP
Force operation
9-1-7
9-2-21
32
SF1
Multi-speed Bit-1
9-2-7
33
SF2
Multi-speed Bit-2
34
SF3
Multi-speed Bit-3
35
SF4
Multi-speed Bit-4
36
SF5
Multi-speed Bit-5
37
SF6
Multi-speed Bit-6
38
SF7
Multi-speed Bit-7
39
OLR
Overload restriction
selection
9-9-2
Function
Number
Symbol
Function name
Page
40
TL
Torque limit enable
9-6-2
41
TRQ1
Torque limit selection bit 1
42
TRQ2
Torque limit selection bit 2
44
BOK
Answer back from Brake
9-7-16
46
LAC
Acceleration/Deceleration
cancellation
9-3-7
47
PCLR
Clearance of position
deviation
9-14-10
50
ADD
Trigger for frequency
addition
9-2-17
51
F-TM
Force terminal
9-1-7
9-2-21
52
ATR
Permission of torque
control
9-6-5
53
KHC
Accumulated input power
monitor clear
10-1-7
56
MI1
General-purpose input 1
12-2-3
57
MI2
General-purpose input 2
58
MI3
General-purpose input 3
59
MI4
General-purpose input 4
60
MI5
General-purpose input 5
61
MI6
General-purpose input 6
62
MI7
General-purpose input 7
65
AHD
Analog command holding
9-2-20
66
CP1
Multistage position settings
selection 1
9-14-2
9-14-5
67
CP2
Multistage position settings
selection 2
68
CP3
Multistage position settings
selection 3
69
ORL
Limit signal of Homing
function
9-14-8
70
ORG
Start signal of Homing
function
73
SPD
Speed/position switching
9-14-12
81
ECOM
EzCOM activation
11-4-2
82
PRG
Program RUN
12-2-2
83
HLD
Acceleration/Deceleration
disable
9-3-4
84
REN
RUN enable
9-4-4
85
PLB
Pulse input B
Can be assigned only to
[C007].
9-5-14
86
DISP
Display lock
7-2-10
91
PSET
Position data presetting
9-14-10
no
no
No assignment
-
