Hitachi WJ C1 Series

Chapter 10 Monitor Functions
10-3-4
10.3.4 Monitor the Operation Mode of the Inverter
 How to check the current load specification selection?
 How to check the current drive motor type (induction motor/PM motor)?
Inverter mode monitor [d060]
 Displays the current inverter mode.
 The inverter mode is changed by "Load type selection [b049]" and "Inverter mode selection
[b171]". For more information, see "8.1.2 Changing the Load Rating of the Inverter" and "8.1.6
Changing the Operation Mode of the Inverter".
 The rated current and current derating characteristics will change depending on the selection of
the load specifications. Check them together.
Code
Item
Description
Data
[d060]
Inverter mode monitor
IM (induction motor), Normal duty
I-C
IM (induction motor), Low Duty
I-V
PM motor
P
Q
A
!
