Chapter 9 Inverter Functions
9-16-3
â–  List of output terminal functions
Data
Symbol
Function name
Page
00
RUN
Running
9-12-1
01
FA1
Constant-frequency reached
9-13-1
02
FA2
Set frequency overreached
9-13-2
03
OL
Overload warning notice
9-11-3
04
OD
Over deviation for PID control
9-8-2
05
AL
Alarm
9-11-1
06
FA3
Set frequency reached
9-13-3
07
OTQ
Over-torque/under-torque
9-6-4
09
UV
Undervoltage
9-9-10
10
TRQ
Torque limited
9-6-2
11
RNT
Accumulated RUN time over
9-11-9
12
ONT
Accumulated power-on time
over
13
THM
Electronic thermal alarm
(Motor)
9-11-5
19
BRK
Brake release
9-7-16
9-14-13
20
BER
Brake error
9-7-20
9-14-13
21
ZS
Zero speed detection
9-13-4
22
DSE
Speed over deviation
9-5-8
9-5-16
23
POK
Positioning completed
9-14-2
24
FA4
Set frequency overreached 2
9-13-2
25
FA5
Set frequency reached 2
9-13-3
26
OL2
Overload warning notice 2
9-11-3
27
Ai1Dc
Analog [Ai1] disconnection
detection
9-11-10
28
Ai2Dc
Analog [Ai2] disconnection
detection
Data
Symbol
Function name
Page
31
FBV
PID feedback comparison
9-8-2
32
NDc
Communication line
disconnection
11-1-1
33
LOG1
Logical operation result 1
9-13-5
34
LOG2
Logical operation result 2
35
LOG3
Logical operation result 3
39
WAC
Capacitor life warning
9-11-7
40
WAF
Cooling-fan life warning
9-11-8
41
FR
RUN command active
9-12-3
42
OHF
Cooling fin overheat warning
9-11-6
43
LOC
Low current signal
9-11-4
44
MO1
General-purpose output 1
12-2-3
45
MO2
General-purpose output 2
46
MO3
General-purpose output 3
50
IRDY
Inverter ready
9-12-4
51
FWR
Forward rotation
9-12-2
52
RVR
Reverse rotation
53
MJA
Major failure
9-11-2
54
WCAi1
Window comparator [Ai1]
9-11-10
55
WCAi2
Window comparator [Ai2]
58
FREF
Frequency reference by
keypad
9-2-3
59
REF
RUN command by keypad
9-1-2
60
SETM
2nd-motor control is selected
9-7-18
62
EDM
STO state monitor output
14-1-3
63
OPO
*1
Option output
-
64
FSC
STO input discrepancy
14-1-4
no
no
No assignment
-
*1. Option output (OPO) is for an extension function in the future and currently not functioning. Do not assign this
function.
