Hitachi WJ C1 Series User Manual

Chapter 18 List of Parameters/Modbus Coil/Register Numbers
18-2-3
Code
Name
Data range
Change
during
running
Modbus communication
Page
Register No.
Data range
Resolution
d083
Trip monitor 3
Trip code (E01.n to E99.n)
-
0026h
0 to 99
-
10-5-1
Inverter status at Trip (Above n: 0 to 9)
-
0027h
0 to 9
-
Output frequency at Trip (Hz)
-
0028h (High)
0029h (Low)
0 to 59000
0.01
Output current at Trip (A)
-
002Ah
Output current
0.01
DC bus voltage at Trip (VDC)
-
002Bh
DC bus voltage
0.1
Accumulated RUN time at Trip (hr)
-
002Ch (High)
002Dh (Low)
Accumulated
RUN time
1
Accumulated power-on time at
Trip (hr)
-
002Eh (High)
002Fh (Low)
Accumulated
power-on time
1
d084
Trip monitor 4
Trip code (E01.n to E99.n)
-
0030h
0 to 99
-
Inverter status at Trip (Above n: 0 to 9)
-
0031h
0 to 9
-
Output frequency at Trip (Hz)
-
0032h (High)
0033h (Low)
0 to 59000
0.01
Output current at Trip (A)
-
0034h
Output current
0.01
DC bus voltage at Trip (VDC)
-
0035h
DC bus voltage
0.1
Accumulated RUN time at Trip (hr)
-
0036h (High)
0037h (Low)
Accumulated
RUN time
1
Accumulated power-on time at
Trip (hr)
-
0038h (High)
0039h (Low)
Accumulated
power-on time
1
d085
Trip monitor 5
Trip code (E01.n to E99.n)
-
003Ah
0 to 99
-
Inverter status at Trip (Above n: 0 to 9)
-
003Bh
0 to 9
-
Output frequency at Trip (Hz)
-
003Ch (High)
003Dh (Low)
0 to 59000
0.01
Output current at Trip (A)
-
003Eh
Output current
0.01
DC bus voltage at Trip (VDC)
-
003Fh
DC bus voltage
0.1
Accumulated RUN time at Trip (hr)
-
0040h (High)
0041h (Low)
Accumulated
RUN time
1
Accumulated power-on time at
Trip (hr)
-
0042h (High)
0043h (Low)
Accumulated
power-on time
1
d086
Trip monitor 6
Trip code (E01.n to E99.n)
-
0044h
0 to 99
-
Inverter status at Trip (Above n: 0 to 9)
-
0045h
0 to 9
-
Output frequency at Trip (Hz)
-
0046h (High)
0047h (Low)
0 to 59000
0.01
Output current at Trip (A)
-
0048h
Output current
0.01
DC bus voltage at Trip (VDC)
-
0049h
DC bus voltage
0.1
Accumulated RUN time at Trip (hr)
-
004Ah (High)
004Bh (Low)
Accumulated
RUN time
1
Accumulated power-on time at
Trip (hr)
-
004Ch (High)
004Dh (Low)
Accumulated
power-on time
1
d090
Warning monitor
Warning code
-
004Eh
Warning code
-
10-5-2
d102
DC bus voltage
monitor
0.0 to 1000.0 (VDC)
1026h
0 to 10000
0.1
10-1-8
d103
BRD load ratio
monitor
0.0 to 100.0 (%)
-
1027h
0 to 1000
0.1
10-1-9
d104
Electronic
thermal load ratio
monitor (Motor)
0.0 to 100.0 (%)
-
1028h
0 to 1000
0.1
10-1-10
d130
Analog input [Ai1]
monitor
0 to 1023
-
108Eh
0 to 1023
1
10-2-2
d131
Analog input [Ai2]
monitor
0 to 1023
-
108Fh
0 to 1023
1
d133
Pulse input [PLA]
monitor
0.00 to 100.00 (%)
-
1091h
0 to 10000
0.01
d153
PID deviation
monitor
-100. 00 to 100.00 (%) (-9999.00
to 9999.00 depending on [A075])
-
10AEh (High)
10AFh (Low)
-999900 to
999900
0.01
10-4-1
d155
PID output
monitor
-100.00 to 100.00 (%)
-
10B2h (High)
10B3h (Low)
-10000 to 10000
0.01
