Hitachi WJ C1 Series

Chapter 3 Main Body of the Product
3-2-3
■ Three-phase 200 V class: C1-110LF
Three-phase 400 V class: C1-110HF/150HF
■ Three-phase 200 V class: C1-150LF
(1) Cooling fan cover
(4) Main body cover
(7) Backing plate
(2) Cooling fan
(5) Terminal block cover
(3) Cooling fin
(6) Control terminal cover
(1)
(2)
(3)
(4)
(7)
(6)
(5)
(1)
(2)
(3)
(4)
(7)
(6)
(5)
