Hiwin D2 Series User Manual

Specifications D2 Series Servo Drive User Manual
2-2 HIWIN MIKROSYSTEM CORP.
MD07UE01-2005
2.1 Drive information
2.1.1 Safety certification
The drive complies with the following safety regulations.
Table 2.1.1.1
EMC
EN 61800-3: 2004 (Category C2)/2012(Category C3)
EN 61000-3-2: 2006/A1: 2009/A2: 2009/A3:2014
EN 61000-3-3: 2013
IEC CISPR 11: 2015/A1: 2016
IEC 61000-4-2: 2008
IEC 61000-4-3: 2006/A1: 2007/A2: 2010
IEC 61000-4-4: 2012
IEC 61000-4-5: 2014
IEC 61000-4-6: 2013
IEC 61000-2-1: 1990
IEC 61000-2-4: 2003
IEC 60146-1-1: 2009
LVD
IEC 61800-5-1: 2007(2nd Edition)
EN 61800-5-1:2007
UL
E348161
2.1.2 Nameplate information
Figure2.1.2.1
Model No.
Input/output voltage
Rated input/output current
Input/output frequency
Phases
220-240V
