Figure9.2.1.1 Status display area
9.2.2 LCD status
The servo status will be displayed in the home page of LCD screen, as shown in figure 9.2.2.1.
(1) SVNRDY: Servo disabled. It is at the “Servo OFF” status. The motor has no power.
(2) SV RDY: Servo enabled. It is at the “Servo ON” status. The motor has power.
When an error or warning occurs, the second line of home page displays an error or warning message
code. For LCD error codes, refer to Sections 9.3 and 9.4 error/warning codes and troubleshooting.
Figure9.2.2.1
1 SVNRDY
X
Error
occurs
1 SVNRDY
E01SHORT
Warning
occurs
1 SV RDY
X
1 SV RDY
W01SWLL
1:X
SVNRDY
1:SVNRDY
ERR E01
1:X
SV RDY
1:SV RDY
WRN W01
(a) LCD abbreviated display symbol
(b) LCD numbered display symbol
Error
occurs
Warning
occurs
