 The output method of emulated Z-phase signal:
a If the option of “Emulated Index Output in every revolution” is not checked, the drive sends
out the Z-phase signal only when it reaches the index position at the first time.
b If the option of “Emulated Index Output in every revolution” is checked, the drive sends out
the Z-phase signal every time when it reaches the index position.
5.2.3 Operation mode configuration
The configuration page for the operation mode is shown in figure 5.2.3.1. After parameters of the previous
two steps have been set, the last step is to set the operation mode for the drive.
Figure5.2.3.1 Operation mode configuration page
Parameters setting area
Mode selection area
Parameters OK/Cancel button
