D2 Series Servo Drive User Manual Wiring
HIWIN MIKROSYSTEM CORP. 4-39
MD07UE01-2005
4.6.1.7 5V TTL interface
Wiring example for the host controller having the 5V TTL interface:
W
V
U
CN1 CN7
CN6
4
CWL-
220
2K
220
2K
6 CCWL-
COM7
I133
I2
30
I329
I427
I528
I626
I732
I831
I99
4.7K
CN6
21A
22/A
48B
49/B
23Z
24/Z
19CZ
CN6
Encoder output
25SG
Signal output
Signal input
ZSP
SVN
GNS
26
LL
MOD
CE
RL
24V
0V
0V
General input
Definited by user
A-phase
output
Z output (open collector)
0V
Controller
B-phase
output
Z-phase
output
mega-fabs
D2 Series Drive
3 CWL+
5 CCWL+
D2-ENE17A
5V TTL type
0V
General output
Definited by user
STEP
( :Twisted pair)
Ic=0.6A(Max.)
Vce=40V(Max.)
DIR
CN6
O1+ 35
O1- 34
O2+ 37
O2- 36
O3+ 39
O3- 38
O4+ 11
O4- 10
24V
R
RDY
ALM
INP
Photo-
Coupler
wiring
Relay
wiring
R
Low-speed pulse input
Low-speed pulse command
(500 Kpps or less)
Figure4.6.1.7.1
General-purpose output;
its function can be
assigned by the user.
General-purpose
input; its function
can be assigned by
the user.
