D2 Series Servo Drive User Manual Wiring
HIWIN MIKROSYSTEM CORP. 4-31
MD07UE01-2005
Figure4.5.2.1
 Output wiring example via relays
Figure4.5.2.2
 Output wiring example via optical couplers
Figure4.5.2.3
O1+
35
O1-
34
O2+
37
O2- 36
O3+ 39
O3-
38
O4+
11
O4-
10
+24VDC
