Figure 39: Components on the Front Panel of a 32-Port EX4300 Switch

5—1— Chassis status LEDsCover panel for uplink module slot

6—2— LCD panel Enter buttonSFP network ports

7—3— Mini-USB console portLCD panel

8—4— SFP+ uplink portsLCD panel Menu button

Figure 40 on page 82 shows the components on the front panel of a 48-port EX4300 switches except

EX4300-48MP and EX4300-48MP-S switches (with an SFP+ uplink module installed).

Figure 40: Components on the Front Panel of 48-Port EX4300 Switches Except EX4300-48MP and

EX4300-48MP-S Switches

5—1— LCD panel Enter buttonMini-USB console port

6—2— SFP+ uplink module (optional)LCD panel

7—3— Network portsLCD panel Menu button

4—Chassis status LEDs

Figure 41 on page 83 shows the components on the front panel of EX4300-48MP and EX4300-48MP-S

switches (with a 4-port 1-Gigabit Ethernet SFP/10-Gigabit Ethernet SFP+ uplink module installed).
