Keysight U8903B - Page 430

A Appendixes
430 Keysight U8903B User’s Guide
Waveform Config
(Abitrary)
Amplitude Set the signal amplitude value.
DC Offset Set the signal DC offset value.
Load File
Load a waveform from a file.
Refer to “Appendix 13: Recall Menu Tree” on page 494 for the recall
menu tree.
Info Display the loaded waveform information.
Waveform Config
(Multitone)
Amplitude Set the signal amplitude value.
DC Offset Set the signal DC offset value.
Start Freq
Set the lowest frequency in the multitone waveform which is usually the
frequency for the first tone.
Stop Freq
Set the highest frequency in the multitone waveform which is usually the
frequency for the last tone.
Freq Spacing
– Linear
–Log
– Custom
Select frequency spacing between the tones.
Custom is selected when the custom multitone waveform is set.
Tones Set the number of signal frequency components.
Length
– 1024
– 2048
– 4096
– 8192
– 16384
– 32768
– 65536
Select the waveform length that determines the number of samples used to
create one iteration of the multitone waveform.
Custom
Apply
Apply the current setting on the selected tone for the custom multitone
waveform.
Optimize Optimize the crest factor for the custom multitone waveform.
Frequency Set the frequency value for the custom multitone waveform.
Amplitude Set the amplitude value for the custom multitone waveform.
Phase Set the phase value for the custom multitone waveform.
Add Above Add the tone above the selected tone for the custom multitone waveform.
Add Below Add the tone below the selected tone for the custom multitone waveform.
Remove Remove the selected tone for the custom multitone waveform.
Clear Clear all the tones in the custom multitone waveform list.
Table A-4 Analog generator menu tree description (continued)
Level 1 Level 2 Level 3 Description
