Appendixes A
Keysight U8903B User’s Guide 439
AES3/SPDIF
Edit Bits
(Consumer)
Word Length
24 bits maximum word
length
–Not indicated
– 20 bits
– 21 bits
– 22 bits
– 23 bits
– 24 bits
20 bits maximum word
length
–Not indicated
– 16 bits
– 17 bits
– 18 bits
– 19 bits
– 20 bits
Select the word length.
Orig S.Freq
–Not indicated
–8 kHz
– 11.025 kHz
– 12 kHz
– 16 kHz
– 22.05 kHz
– 24 kHz
– 32 kHz
– 44.1 kHz
– 48 kHz
– 88.2 kHz
– 96 kHz
– 176.4 kHz
– 192 kHz
– Reserved 1
– Reserved 2
Select the original sample frequency value.
CGMA-A
– Copying Permitted
– Condition Not Used
– One Generation
Copy
– Copying Denied
Select the CGMA-A type.
Edit Bits
(Professional)
Select Byte Select the byte and edit the byte.
Audio Mode
– Non-Linear PCM
– Linear PCM
Select the audio mode.
Emphasis
–Not indicated
– No pre-emphasis
– 50/15 μs
– CCITT J.17
Select the emphasis type.
Table A-5 Digital generator menu tree description (continued)
Level 1 Level 2 Level 3 Level 4 Description
