A Appendixes
438 Keysight U8903B User’s Guide
AES3/SPDIF
Edit Bits
(Consumer)
Category
– General
– Laser Optical
– D/D Converter
– Magnetic
– Digital Broadcast 1
– Digital Broadcast 2
– Musical Instrument
– ADC Non Copyright
– Solid State Memory
– ADC Copyright
– Experimental
– Reserved 1
– Reserved 2
Select the category code type.
Source Num 0 to 15 Set the source number.
Channel Num 0 to 15 Set the channel number.
Sample Freq
–Not indicated
– 22.05 kHz
–24 kHz
–32 kHz
– 44.1 kHz
–48 kHz
– 88.2 kHz
–96 kHz
– 176.4 kHz
– 192 kHz
– 768 kHz
Select the sample frequency value.
Clk Accuracy
– Level 1
– Level 2
– Level 3
– Reserved
Select the clock accuracy type.
Max Word Len
–24 bits
–20 bits
Select the maximum word length.
Table A-5 Digital generator menu tree description (continued)
Level 1 Level 2 Level 3 Level 4 Description
